Feature

- BUDGET AND SPACE SAVING INSTALLATION

The system incorporates most of the current PA functions plus emergency and normal broadcasting abilities thus allowing budget and space saving installation.

- DUAL BROADCASTING SYSTEM

With two-channel (300W+300W) high power amplifier built-in, dual broadcasting is possible in 24 Zones separated by A/b channels.

- DIGITAL PROCESSING & DIGITAL AMPLIFIER

Adopting the use of clAss-D Amplifier to reduce the total weight, power consumption and operating temperature.

- BUILT IN VARIOUS SOUND SOURCES

The system provides FM tuner, Media (cD/DRP/Usb) player and two AUX (1,2) inputs for flexible usage.

- LIFE TIME EXTENSION OF CD MECHANISM

Has the ability to copy the music cD to the internal memory (DRP) to extend the life of the CD mechanism.

- USB HOSTING

MP3/WMA files on the USB memory can be copied to internal memory (DRP) or play directly.

- REMOTE CONTROL SUPPORT

PAC-5000A: Using Rs-232c terminal allows remote control from Windows application on the PC.

PAC-5600: Using a network port for remote control from the web page is possible.

※ However, CD EJECT, TUNER Memory operation including each input level volume cannot be controlled.

- SYSTEM EXPANSION

System can be expanded up to 4 units via the lInK-In/oUt terminals while sharing the audio source. (MASTER 1 Unit, SLAVE 4 Units)

- 24 CHANNEL SPEAKER SELECT (ZONE 1~ZONE 24)

The system provides 24 channel zone selections, which can be divided into two groups for multiple broadcast areas and with system expansion total of 120 channels can be operated.

- EQ ADJUSTMENT

EQ adjustment is possible with built-in DSP.

- REMOTE MIC CONNECTION

Maximum of four remote MIcs can be connected to one unit of the system, and with installation of key pad one of the four units can be used up to maximum of 120 channels.

- BUILT IN MONITOR SPEAKER

One can monitor the broadcast content with a built-in monitor speaker.

- EMERGENCY POWER AND BATTERY CHARGING

System has battery charge connect terminal for battery charge to provide emergency power.

- FIRE DETECTION AND EMERGENCY BROADCASTING

The system provides 24 channel sensor input terminals for automatic fire alarm broadcasting. It also provides the recording function of personalized alarm message.

- CHIME AND SIREN

Built-in chime (4 scale, 2 scale) and sire (continuous Wave) can be used to broadcast in the event of an emergency. Also users can change the siren and chime.

- INCREASED INPUTS MIC/LINE

System has 5 MIC/LINE input jacks that can be selected by a switch, phantom power (Dc 24V) is also supplied for enhanced compatibility.

- BUILT IN EM MICROPHONE (CONDENSER MICROPHONE)

EM microphone is built-in to the front panel making emergency broadcast a simple task.

- MP3 / WMA SUPPORT

Unit supports MP3/WMA and CD-DA.

- PRE-PROGRAMMED BROADCASTING

Broadcast can be pre-programmed by either Pc tIMeR or stored source.

PAC-5600: Pre-Program Maximum 50/Holiday Maximum 30 (stored source, PC TIMER).

PAC-5000A: Pre-Program Maximum 100 (PC TIMER).

(Pre-Programs can be controlled by broadcasting web pages and Windows applications)

- RACK MOUNT

Rack mount bracket is included with the unit.

- SPEAKER LINE CHECK FUNCTION (PAC-5600 ONLY)

Check connected speaker for functionality.

- BATTERY CHECK FUNCTION (PAC-5600 ONLY)

Check the condition of the battery.
