product detail
There is LED status indicator
Operating temperature: -40oC - 70oC
Nominal voltage: 250VAC
Connection wire section: 2.5 sq.mm
Parameter coil coil relay
| coil infomation | DC | AC | AC | AC |
| Voltage operates normally | 24VDC | 24VAC | 110VAC | 230VAC |
Maximum permissible voltage |
26.4VDC | 26.4VAC | 132VAC | 264VAC |
capacitycoil (mW) |
400mW | - | 0.75 VA | - |
Parameter to relay relay
+ Line and rated voltage: 5A 250VAC / 30 VDC
+ Mechanical strength: 2x107 OPS
+ Power durability: 1x105 OPS
